Specifications
| Frequency Range (-10 dB) | 65 - 20000 |
| Suspension | (6) M8 threaded points |
| Weatherized | No |
| Minimum Impedance | 6 |
| HF Transducer | One 1.3-inch (33 mm) diaphragm ICT-1-8 compression driver |
| Speaker Type | Full-Range, Two-Way |
Specifications |
|
| Frequency Response (-3 dB)¹ | 110 - 16000 |
| Max. SPL/1m (calc)² | 120 |
| Coverage (Nominal -6 dB) H | 90 |
| LF Transducer | One 6.5-inch (165 mm) ICT-6.5-8 woofer |
| Coverage (Nominal -6 dB) V | 50 |
| Power Rating | 640 |
| System Power Handling (Continuous/Program/Peak) | 160//640 |
| Connector Type | 4-pin Phoenix/Euroblock screw terminals (up to 10 AWG wire) |
| Enclosure Material | 9-ply hardwood plywood |
| Grille | 18-gauge steel with cloth behind |
| Available Color | Black or white |
| Height | 209 |
| Width | 370 |
| Recommended High-Pass Frequency | 90 |
| Depth | 207 |
| Weight Net | 6.53 |
| Shipping Weight | 9.12 |
| Nominal Impedance | 8 |
| Waveguide | 6 in. x 6 in., rotatable |
| Axial Sensitivity (SPL, 1 W @ 1 m) | 92 |
| Passive Power Handling | 640 |
| Finish | Textured paint |
Tags:
EVU-1062/95-WHT
